Sync Audio&Text

TODO

the latest model defaults.sync has audioProps and textProps but UI does not have them yet
update page3/layers
- alphabet_sync.lua,
- iamacat_sync.lua
- mynameiskwik_sync.lua
props.text –> props.line
props.languge –> props.line.en, props.line.jp and textProps.language = {“en”, “jp”}

default

local M = {
  name = "alphabet",
  class = "sync",
  controls = {
    autoPlay     = true,
    delay        = nil,
    fadeDuration = 1000,
    speakerIcon  = true,
    wordTouch    = true,
  },
  audioProps = {
    filename = "alphabet.mp3",
    channel = 2,
    volume      = 10,
  },
  textProps = {
    folder       = nil,
    font         = nil1,
    fontColor   = { 1,1,1 },
    fontColorHi = { 1, 1, 0 },
    fontSize    = 36,
    language    = nil,
    padding     = 10,
    readDir     = "leftToRight",
    sentenceDir = "alphabet", -- wordTouch
  }
}

M.line = {
  { start =  0, out = 1000, dur = 0, name = "A", file = "a.mp3", action = "onComplete"},
  { start =  1000, out = 2000, dur = 0, name = "B", file = "b.mp3", action = "onComplete"},
  { start =  2000, out = 3000, dur = 0, name = "C", file = "c.mp3", action = "onComplete"},
}

Sync Audio & Text

test/base-proj/Solar2D/App/bookFree/components/page3/index.lua

local sceneName = ...
--
local scene = require('controller.scene').new(sceneName, {
    name = "page3",
    components = {
      layers = {
            { test={}},
            { alphabet    = {class={"sync"}}},
            { iamacat     = {class={"sync"}}},
            { mynameiskwik = {class={"sync"}}},
      },
      audios = {
        long  = {"GentleRain", "Tranquility" },
        short ={"ballsCollision"} ,
      },
      groups = {},
      timers = {},
      variables = {},
      page = { }
    },
    commands = { "onComplete", "play" },
    onInit = function(scene) print("onInit") end
})
--
return scene

files(mp3 and text) are structeud in the following patterns A-D. See the examples of sync audio text in page3/index.lua

A: alphabet

not multi-lingual

word touch enabled and files are in alphabet folder

clicking a word in a line, the word.mp3 is played

── sync
├── alphabet
│   ├── a.mp3
│   ├── b.mp3
│   └── c.mp3
├── alphabet.mp3
├── alphabet.txt

B: iamcat

en and jp
word touch enabeld and mp3 files of words are in i_am_cat folder

── sync
    ├── en
    │   ├── i_am_a_cat
    │   │   ├── am.mp3
    │   │   ├── cat.mp3
    │   │   └── i.mp3
    │   ├── i_am_a_cat.mp3
    │   ├── i_am_a_cat.txt
    └── jp
        ├── i_am_a_cat
        │   ├── am.mp3
        │   ├── cat.mp3
        │   └── i.mp3
        ├── i_am_a_cat..txt
        ├── i_am_a_cat.mp3

C: mynameiskwik

en and jp
- mp3 and txt are in page3 folder
no word touch

── sync
    ├── en
    │   └── page3
    │       ├── my_name_is_kwik.mp3
    │       └── my_name_is_kwik.txt
    └── jp
        └── page3
            ├── my_name_is_kwik.mp3
            └── my_name_is_kwik.txt

D: my father is nice

en and jp
no word touch

── sync
    ├── en
    │   ├── my_father_is_nice.mp3
    │   ├── my_father_is_nice.txt
    └── jp
        ├── my_father_is_nice.mp3
        ├── my_father_is_nice.txt

A: alphabet

local props = {
  name = "alphabet",
  filename = "alphabet.mp3",
  type = "sync",
  autoPlay = true,
  channel = 2,
  folder = nil
}

props.text = {
  { start =  0, out = 1000, dur = 0, name = "A", file = "a.mp3", action = "onComplete"},
  { start =  1000, out = 2000, dur = 0, name = "B", file = "b.mp3", action = "onComplete"},
  { start =  2000, out = 3000, dur = 0, name = "C", file = "c.mp3", action = "onComplete"},
}

props.wordTouch    = true
props.sentenceDir  = "alphabet" -- wordTouch
props.layer        = "alphabet"

B: i am cat

local props = {
  name      = "i_am_a_cat",
  filename = "i_am_a_cat.mp3",
  type      = "sync",
  language  = {},
  autoPlay  = true,
  channel   = 2,
  folder    = nil
}

props.language.en = {
  { start =  0, out = 500, dur = 0, name = "I", file = "i.mp3"},
  { start =  500, out = 1000, dur = 0, name = "am", file = "am.mp3"},
  -- { start =  1000, out = 1000, dur = 0, name = "a", file = nil},
  { start =  1000, out = 1500, dur = 0, name = "a cat.", file = "cat.mp3", action = "onComplete"},
}

props.language.jp ={
  {start =  0, out = 500, dur = 0, name = "ぼく", file = "i"},
  {start =  500, out = 1000, dur = 0, name = "ねこ", file = "cat", action = "onComplete"},
}

props.wordTouch    = true
props.sentenceDir  = "i_am_a_cat" -- wordTouch
props.layer        = "iamacat"

C: my name is kwik

local props = {
  name =  "my_name_is_kwik",
  filename = "my_name_is_kwik.mp3",
  type =  "sync",
  language = {},
  folder = "page3",
}
--
-- action is added by sync props
--
props.language.en = {
  { start =  0, out = 500, dur = 0, name = "My", file = "" },
  { start =  500, out = 1000, dur = 0, name = "name", file = ""},
  { start =  1000, out = 1000, dur = 0, name = "is", file = ""},
  { start =  1000, out = 1500, dur = 0, name = "Kwik.", file = "", action = "onComplete"},
}

props.language.jp = {
  {start =  0, out = 500, dur = 0, name = "なまえ", file = ""},
  {start =  500, out = 500, dur = 0, name = "は", file = ""},
  {start =  500, out = 1000, dur = 0, name = "くいっく", file = "", action = "onComplete"},
}
props.wordTouch    = false
props.sentenceDir  = nil -- wordTouch
props.readDir      = "leftToRight"
props.layer        = "mynameiskwik"

D: my father is nice

local props = {
  name =  "myfatherisnice",
  filename = "my_father_is_nice.mp3",
  type =  "sync",
  language = {},
  folder = nil,
}
--
-- action is added by sync props
--
props.language.en = {
  }

props.language.jp = {
}
props.wordTouch    = false
props.sentenceDir  = nil -- wordTouch
props.readDir      = "leftToRight"
props.layer        = "myfatherisnice"
